Adjustable Rear Spring Plates for IRS Suspension: Beetle (1968-1970), Karmann Ghia (1968-1974), Type 3 (1968-1973)
SKU
AC501325
Adjustable Rear Spring Plates for IRS Suspension: Beetle (1968-1970), Karmann Ghia (1968-1974), Type 3 (1968-1973)
SKU
AC501325
Reviews & Ratings
- Adjustable rear spring plates for IRS rear suspension
- Simplifies rear torsion bar adjustment for ease of use
- Compatible with 21 3/4 inch torsion bars (late swing axle)
- Requires 2" inner and 1 7/8" outer torsion arm grommets
These adjustable rear spring plates are designed to make rear torsion bar adjustments a breeze. Ideal for IRS rear suspension, they eliminate the hassle of manual adjustments, allowing you to fine-tune your ride height and suspension setup with ease. They are specifically made to work with 21 3/4 inch torsion bars, which were commonly fitted to most late swing axle VW Beetles.
If your Beetle does not currently have these torsion bars, they can be sourced from a donor vehicle or purchased separately. In addition, the plates require 2-inch inner torsion arm grommets and 1 7/8-inch outer grommets for proper fitment. Perfect for enthusiasts looking to enhance their suspension system, these adjustable spring plates provide durability and reliability for both restoration and performance upgrades.
£187.96 £156.63
Product Information
This product is intended for use as originally designed and should not be modified for alternative purposes. Please ensure it is installed by a qualified professional. Fitting instructions are typically not included with the product. Contacts
| Also known as | AC501325 |
|---|---|
| Fitting Info | Requires Urethane Torsion Arm Grommets AC510003 (inner) and AC510002 (Outer) to fit. For 21 3\/4'' Torsion Bars The spring plate is a universal aftermarket replacement. The two holes closest to the end fit both the three bolt and four bolt trailing arms. The centre hole lines up with the centre hole on the four bolt trailing arms. It is expected that you drills/slots the spring plate for the remaining bolt closest to the torsion bar. This is because the holes in the trailing arms are opposite each other on the mounting tab. The 4 bolt is at the top while the three bolt is at the bottom. |
| Marque | Volkswagen |
| Vehicle | Beetle, Karmann Ghia, Beetle Cabriolet, Buggy/Baja |
| Weight (kg) | 4.97 |
| Brand | USA |
| Quality | Good Quality |
| Unit of sale | Pair |
Fits Vehicles
| Beetle | 1968-1970 |
|---|---|
| Karmann Ghia | 1968-1974 |
| Beetle Cabrio | 1968-1970 |
| Type 3 | 1968-1973 |
| Buggy/Baja | 1968-1970 |
Product Questions
which way do you turn the screw to raise the ride hieght, and which way to lower?
Question by: callum on 16 Nov 2023, 16:01
Same as a normal screw turning right will tighten it bye pushing the screw up and left will loosen it bringing it down
Answer by: Rob Baxter (Admin) on 17 Nov 2023, 09:45
