CB Performance 044 CNC Ultra Mag Plus Cylinder Heads 90.5/92mm 44x37.5mm Pair: Beetle (1960-1979), T2 Bay (1968-1979), Splitscreen (1960-1967)

SKU
AC1031457

CB Performance 044 CNC Ultra Mag Plus Cylinder Heads 90.5/92mm 44x37.5mm Pair: Beetle (1960-1979), T2 Bay (1968-1979), Splitscreen (1960-1967)

SKU
AC1031457
Reviews & Ratings

CB Performance 044 CNC Ultra Mag Plus cylinder heads cut for 90.5/92mm barrels and pistons. With 44mm Inlet and 37.5mm Exhaust valves.

All ULTRA MAG Plus Cylinder Heads feature full CNC Porting. The intake ports flow 120% more than stock VW cylinder heads. To handle the extra flow capabilities of the intake ports, the combustion chambers are also CNC machined for maximum power and flame travel. Spark plugs are secured in re-located 12mm spark plug bosses for increased strength and durability. The exhaust charge is accelerated through the CNC Machined exhaust ports.

Based on the same ''ALL NEW FOR 2017'' 044™ Castings as the rest of the 044™ line up, ULTRA MAGS have been taken to the highest level of performance with CNC porting.

ULTRA MAG Plus Cylinder Heads (sometimes referred to as Oval Ports) are race ready and offer maximum HP potential for ultra high performance engines right out of the box! We do it all, just bolt 'em on!

Features:
- CNC Ported and Polished for Increased Flow
- 12mm 3/4'' Reach Spark Plug Holes
- 44mm x 37.5mm SUPERGRIP 214N Single Groove Stainless Steel Valves with Stellite Tips
- SUPERGRIP Chromoly Valve Spring Retainers
- SUPERGRIP Single Groove Valve Locks
- Performance 4 Angle Valve Job (30, 45, 60 & 75) on seats
- Manganese Bronze Racing Valve Guides
- Tungsten Carbide Alloy Valve Seats
- Dual Hi-Rev Chrome Silicon Valve Springs

Sold in pairs

€1,627.13 €1,390.71

Need help?

Contact us


Buy NOW, Pay LATER

Klarna now available in checkout


This product is special order and will be ordered for you from the manufacturer. We require payment at the time of order. Special Order - delivery 12 weeks

Special Order - delivery 12 weeks
CB Performance

Product Information

Product Attributes
Also known asAC1031457
MarqueVolkswagen
VehicleBeetle, Type 2 Split, Type 2 Bay, Karmann Ghia, Beetle Cabriolet, Type 3
Inlet Valve44
BrandCB Performance
QualityTop Quality
Unit of salePair
Standard or UpgradeUpgrade
Supplier code1457
Weight1.00

Fits Vehicles

Product Vehicle Years
Beetle1960-1979
T2 Bay1968-1979
Splitscreen1960-1967
Karmann Ghia1960-1974
Beetle Cabrio1960-1979
Type 31961-1975
